SYPG Drum Type Spraying System
SYPG Drum Type Spraying System

SYPG Drum Type Spraying System


Model: SYPG Series

Capacity: 3-15t/h

Certification: CE & SGS & ISO

Spraying error: ≤1%

Product Description

SYPG Drum Type Spraying System Details

SYPG Drum Type Spraying System
Henan Richi Machinery SYPG Series Drum Spraying System, sprays oils, enzymes, vitamins, organic acids, microorganisms and other nutrients and medicines on the surface of pellets. Drum spraying, fully contact with the surface of pellets, spraying uniform. Computerized control of additions, more accurate measurement. The nutrition of pellets is balanced, and the pellets are more attractive and disease-resistant.

Features

1. Excellent afterward adding technology,high uniformity of spraying.

2. Drum-type spraying system, air atomizing nozzle, fully contact with pellet surface.

3. Computer-controlled additive amount, more accurate measurement.

4. The pellets have balanced nutrition, more palatability and disease resistance.

5. Simplify control and operation procedures without pressure control.

6. There is no need to set nozzle combination according to spraying proportion, so it has high reliability.

Parameter

Capacity(t/h) Spraying proportion Spraying error Main motor power(kw) Belt-conveyer power(kw) Rotating speed(rpm)
3-15 1-3% ≤1% 22 0.75 10.5
